NL204153AC21-22
NL204153AC21-22 Grundlæggende oplysninger
| Panel Model | NL204153AC21-22 |
|---|---|
| Panelmærke | NLT |
| descrition | a-Si TFT-LCD ,21.3 inch, 2048×1536 |
| Paneltype | a-Si TFT-LCD |
| NL204153AC21-22 pris | Anmodning Pris og leveringstid |
| Driftstemperatur | 0 ~ 60 °C |
| Stuetemperatur | -20 ~ 60 °C |
NL204153AC21-22 Mekaniske egenskaber
| Punktopløsning | 2048(RGB)×1536 (QXGA) |
|---|---|
| Pixel-konfiguration | RGB Vertical Stripe |
| Pixel Density | 120 PPI |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot pitch | 0.0705×0.2115 mm (H×V) |
| Pixel Pitch | 0.2115×0.2115 mm (H×V) |
| Vægt | 2.70/2.98Kgs (Typ./Max.) |
| Overflade | Antiglare, Hard coating (2H) |
| Aktivt område | 433.152×324.864 mm (H×V) |
| Bezel Area | 438.2×330.0 mm (H×V) |
| Skitse Dimension | 457×350 mm (H×V) |
| Skitse dybde | 21.5/23.0 (Typ./Max.) mm |
| Holes & Brackets | Side mounting holes (4-M3) on left, right bezel |
| Landskab eller Portræt | Landscape type |
| Berøringspanel | Without |
NL204153AC21-22 Optiske funktioner
| Visningstilstand | UA-SFT, Normally Black |
|---|---|
| lysstyrke | 800 cd/m² (Typ.) |
| Kontrastforhold | 1400 : 1 (Typ.) (Transmissive) |
| Skærmfarve | 1.07B (10-bit) |
| Color Gamut | 72% NTSC (CIE1931) |
| Responstid | 20/20 (Typ.)(Tr/Td) |
| Synsvinkel | 88/88/88/88 (Typ.)(CR≥10) (L/R/U/D) |
| Visning af retning | Symmetry |
| Hvid farve Kromaticitet | Wx:0.299; Wy:0.315 |
| Hvid Variation | 1.25 (Max.)(9 points) |
| Sollys Læses | Y |
NL204153AC21-22 Elektronik Feature
| Lodret frekvens | 60Hz |
|---|---|
| Omvendt scanning | No |
| Total strømforbrug | 58W (Typ.) |
NL204153AC21-22 Backlight System
| Lampens position | Edge light type (Top and Bottom) |
|---|---|
| Lampetype | WLED |
| Lampens levetid | 70K(Typ.) (Hours) |
| Interface Type | Connector |
| Lamp Driver Board | 4.2/5.8A (Typ./Max.) |
NL204153AC21-22 Signal Interface
| Signalkategori | LVDS |
|---|---|
| Signalklasse | LVDS (4 ch, 10-bit) |
| Indgangsspænding til panel | 12.0V (Typ.) |
| Indgangsstrøm for panel | 590/980mA (Typ./Max.) |
| Interface Type | Connector |
| Signal Interface | JAE - FI-RE51S-HF, Pitch:0.5 mm, Pin:51 pins |
